Video Training Series: "How to Read and Interpret Automotive Electrical Wiring Diagrams"

[mrrsm]

If you are faced with having to read and interpret Automotive Electrical Diagrams as most of us are forced to do from time to time… Their Language, Color Coding, Numbering and Symbolism can often become confusing and distracting to anyone not steeped in Electrical Engineering. One of our frequent Youtube Go To Guys are the Good Folks over at “realfixesrealfast”.

The Head Honcho ...Duane … has managed to put together a very nice Video Series that covers this very topic and allows the viewer to download, save and refer to this Instructional Material when it seems important to know enough to find out What Has Gone Electrically Wrong… ? What the Components Are in The Circuits...? How The Wiring set ups Perform…? Where these Items are located....? and finally...How to Fix The Problems ...? By following the common denominators of Automotive Wiring Diagrams as References:

This is the Introductory Video to The Course:

The Best way to follow each Training video is to visit RealFixesRealFast Youtube Channel to follow them:

This is an Older Training Document that has some additional information on the subject:

http://www.ave.dee.isep.ipp.pt/~mjf/act_lect/SIAUT/Material Auxiliar/Automotive electrical systems.pdf



[mrrsm]

If you have made the leap towards using "HP-Tuners" or have any need to build your own PCM-ECM Bench Test Harness for programming Calibrations on GM Vehciles... THIS Training Video "Kills TWO Bird...with One Stone" by explaining (1) "How to Read and Interpret Automotive Engine Wiring Diagrams" and (2) ..."How to De-Pin and Re-Pin a PCM-ECM Harness and gather the Necessary Wires for the Harness under your Control":

And MUCH More Automotive Training Videography is also available via THIS Link to the VOP (Video Original Posters):
